Lumiform Orbit LS - 24V
technical data sheet
Order Code:
I1M3E1B9D2CG
Legacy Code:
I1M3E1B9D2CG
Profile Capabilities
Top & Side: 47.24in (1200mm)
Top & Side: 47.24in (1200mm)
Top & Side: 47.24in (1200mm)
Temperatures
Ambient Operating Temperature:
-40°F to 131°F (-40°C to 55°C)
Max Mounting Surface Temperature:
185°F (85°C)
Ambient Installation Temperature:
-40°F to 131°F (-40°C to 55°C)
Humidity (Non-Condensing):
0-95%
Fixture Storage Temperature:
-40°F to 140°F (-40°C to 60°C)
Thermal Management:
Free air convection
Certifications & Features
FLAME
UV
Solvent
Salt Water
UV
Solvent
Salt Water
Electrical
Operating Voltage
24V DC CR
Circuit Type
Current Regulated (CR)
Power Consumption
2.43W/ft (8W/m)
IC Type
Fixture Specifications
LED Function
Static
LED Chip + CRI
Pro LED Chip
LED COunt
46 LEDs/ft (154LEDs/m)
Order Unit (Cutting Unit)
3.94in (100mm)
Max Run Length: 1 Connector
(Full/Dynamic Loads)
26.25ft (8m) / N/A
Max Run Length: 2 Connectors (Full/Dynamic Loads)
26.25ft (8m) / N/A
UL Class 2 Max Run
N/A
LED COLOR
Blue
Cord Color
White (Black available upon request)
Jacket/base + Lens Color
White Jacket/Black Base + Diffused
Connectors
Silicone Seamless with Screw Lock Connectors
Mounting
Stainless Steel In-Ground Flexible
OPtical Parameters
Color Breakdown
Blue
Wavelength/CCt
468-474nm
Lumen Count
>34lm/ft (110lm/m)
LUMEN MAINTENANCE
Fixture cri
N/A
led cri
N/A
fixture color tolerance
N/A
led color tolerance
N/A
Safety/Testing + NOTES
UL CERTIFICATE #
UL 2108 Class 2
Report referance#
E347880/20130508
Tested to UL2108 Class 2 by Underwriters Laboratory for use in the USA and Canada. Exceeds ANSI C78.377A, CE, and RoHS standards. Must be used under Class 2 ratings to maintain certification.
*Maximum IP and IK ratings achievable with appropriate accessories. Max run length is based on silicone seamless connectors and excludes connector length, see connector specs for details. The Current Regulated (CR) Integrated Circuit extends max run length. Do not use a CC or CR power supply, as it may cause damage. Silicone products maintain ≤3 SDCM within a production run and <5 SDCM between production runs. Max run length is based on static full load unless otherwise noted for dynamic use. Due to production limits, max run length is 10m—even with double power feeds. Maximum run length of the silicone diffuser is 98.42ft (30m). Running length is based on voltage drop testing with a 0.3m (0.98ft) cable.
glls.com | 1.888.580.6366 | 1075 american pacific dr., sutie A, henderson, NV 89074
Version 2.0
Updated On
August 19, 2026
Lumiform Orbit LS - 24V
technical data sheet
Legacy Product CODE
I1M3E1B9D2CG
NEW PRODUCT CODE
I1M3E1B9D2CG
PHysical
electrical
operating voltage
24V DC
Circuit type
Current Regulated (CR)
power consumption
2.43W/ft (8W/m)
IC Type
Blue
fixture specifications
led function
Static
led chip + CRI
Pro LED Chip
led count
46 LEDs/ft (154LEDs/m)
temperatureS
Ambient Operating
-40°F to 131°F (-40°C to 55°C)
thermal management
Free air convection
Ambient installation
-40°F to 131°F (-40°C to 55°C)
max mounting surface
185°F (85°C)
fixture storage
-40°F to 140°F (-40°C to 60°C)
humidity non condensing
0-95%
